Xiangrui Optoelectronics
1 / 3
| Part Name | Material | Thickness |
|---|---|---|
| Cover Glass | Chemically strengthened glass, Printing black ink | 1.1mm |
| SCA | Solid state optical adhesive | 0.25mm |
| Sensor Glass | Double ITO shadow cancelling glass | 0.7mm |
| Item | Contents | Unit |
|---|---|---|
| Product Size | 13.3 | inch |
| CG Outline | 317.02 * 188.57 | mm |
| Sensor Outline | 307.20 * 182.65 | mm |
| View Area | 295.02 * 166.57 | mm |
| IC Type | ILI2511 | - |
| Interface | USB & I2C | - |
| TFT Resolution | 1920 * 1080 | - |
| Response | ≤ 25 | ms |
| Touch Point | 10 | points |
The Glass-on-Glass (GG) structure offers enhanced durability and reliability, ensuring the panel withstands the rigors of daily use in demanding environments.
Employs advanced capacitive touch technology for precise and accurate response. Supports seamless swiping, tapping, and pinching gestures.
Adhesive thickness and base materials can be selected and matched to customer specifications, allowing tailored integration into various products.
An ideal choice for a wide range of touch panel applications, including consumer electronics, industrial control systems, and automotive displays.
It features a Glass-on-Glass (GG) structure, consisting of a 1.1mm chemically strengthened cover glass, 0.25mm SCA optical adhesive, and a 0.7mm double ITO shadow-cancelling sensor glass.
The touch panel is equipped with the ILI2511 controller IC and supports both USB and I2C interfaces for flexible system integration.
Yes, the thickness and material of the base adhesive can be fully customized and selected according to specific customer requirements and application needs.
This capacitive touch panel supports up to 10 simultaneous touch points, enabling smooth multi-touch gestures like pinching, zooming, and swiping.
The panel features a rapid response time of ≤25 ms and is fully compatible with TFT displays featuring a resolution of 1920*1080.
Due to its durable GG structure and responsive touch capabilities, it is widely used in consumer electronics, industrial control terminals, and automotive display systems.
